DESCRIPTION
PRODUCTS DESCRIPTION
| Specifications | |||
| Number of pins: | 3 Pin | Key Position: | Standard key |
| Left Connector: | IEC C13 | Right Connector: | IEC C14 |
| AWG Gauge: | 14AWG ~ 18awg | Connection Type | Plug and unplug |
| Wires & Cables Length: | Customization length | ||
| Material | |||
| Housing & Insulation: | PA, Black | Contacts: | Copper Alloy, Gold-Plated |
| Shell: | - | Sealing: | - |
| Shielding: | - | Overmolding: | PVC |
| Wires & Cables Conductor: | Tinned Copper | Wires & Cables Jacket: | PVC or Rubber |
| Technical Characteristics | |||
| Rated Current: | 16A | Rated Voltage: | 300V |
| Rated Temperature | -20°C ~ +80°C | Flame Retardant Grade: | VW-1 |
| Insulation Resistance: | ≥ 100 MΩ | Contact Resistance: | ≤10mΩ |
| Durability: | ≥ 1000 Times | Protection Grade: | - |
| Product Certification: | CE, UL ,RoHS, REACH | Production Design Standards: | IPC620 |
| Application | |||
